2.4.10.1. LSRKStep User-callable functions

This section describes the LSRKStep-specific functions that may be called by the user to setup and then solve an IVP using the LSRKStep time-stepping module. As mentioned in Section §2.4.3, shared ARKODE-level routines may be used for the large majority of LSRKStep configuration and use. In this section, we describe only those routines that are specific to LSRKStep.

As discussed in the main ARKODE user-callable function introduction, each of ARKODE’s time-stepping modules clarifies the categories of user-callable functions that it supports. LSRKStep supports the following categories:

temporal adaptivity

LSRKStep does not have forcing function support when converted to a SUNStepper or MRIStepInnerStepper. See ARKodeCreateSUNStepper() and ARKStepCreateMRIStepInnerStepper() for additional details.

2.4.10.1.1. LSRKStep initialization functions

void *LSRKStepCreateSTS(ARKRhsFn rhs, sunrealtype t0, N_Vector y0, SUNContext sunctx);

This function allocates and initializes memory for a problem to be solved using STS methods from the LSRKStep time-stepping module in ARKODE.

Arguments:

rhs – the name of the C function (of type ARKRhsFn()) defining the right-hand side function.
t0 – the initial value of \(t\).
y0 – the initial condition vector \(y(t_0)\).
sunctx – the SUNContext object (see §1.3)

Return value:

If successful, a pointer to initialized problem memory of type void*, to be passed to all user-facing LSRKStep routines listed below. If unsuccessful, a NULL pointer will be returned, and an error message will be printed to stderr.

void *LSRKStepCreateSSP(ARKRhsFn rhs, sunrealtype t0, N_Vector y0, SUNContext sunctx);

This function allocates and initializes memory for a problem to be solved using SSP methods from the LSRKStep time-stepping module in ARKODE.

Arguments:

rhs – the name of the C function (of type ARKRhsFn()) defining the right-hand side function.
t0 – the initial value of \(t\).
y0 – the initial condition vector \(y(t_0)\).
sunctx – the SUNContext object (see §1.3)

Return value:

If successful, a pointer to initialized problem memory of type void*, to be passed to all user-facing LSRKStep routines listed below. If unsuccessful, a NULL pointer will be returned, and an error message will be printed to stderr.

2.4.10.1.2. Optional input functions

int LSRKStepSetSTSMethod(void *arkode_mem, ARKODE_LSRKMethodType method);

This function selects the LSRK STS method that should be used. The list of allowable values for this input is below. LSRKStepCreateSTS() defaults to using ARKODE_LSRK_RKC_2.

Arguments:

arkode_mem – pointer to the LSRKStep memory block.
method – Type of the method.

Return value:

ARK_SUCCESS if successful
ARK_ILL_INPUT if an argument had an illegal value (e.g. typo in the method type).

int LSRKStepSetSSPMethod(void *arkode_mem, ARKODE_LSRKMethodType method);

This function selects the LSRK SSP method that should be used. The list of allowable values for this input is below. LSRKStepCreateSSP() defaults to using ARKODE_LSRK_SSP_S_2.

Arguments:

arkode_mem – pointer to the LSRKStep memory block.
method – Type of the method.

Return value:

ARK_SUCCESS if successful
ARK_ILL_INPUT if an argument had an illegal value (e.g. typo in the method type).

Allowable Method Families

enum ARKODE_LSRKMethodType

enumerator ARKODE_LSRK_RKC_2: Second order Runge–Kutta–Chebyshev method

enumerator ARKODE_LSRK_RKL_2: Second order Runge–Kutta–Legendre method

enumerator ARKODE_LSRK_SSP_S_2: Second order, s-stage SSP(s,2) method

enumerator ARKODE_LSRK_SSP_S_3: Third order, s-stage SSP(s,3) method

enumerator ARKODE_LSRK_SSP_10_4: Fourth order, 10-stage SSP(10,4) method

int LSRKStepSetSTSMethodByName(void *arkode_mem, const char *emethod);

This function selects the LSRK STS method by name. The list of allowable values for this input is above. LSRKStepCreateSTS() defaults to using ARKODE_LSRK_RKC_2.

Arguments:

arkode_mem – pointer to the LSRKStep memory block.
emethod – the method name.

Return value:

ARK_SUCCESS if successful
ARK_ILL_INPUT if an argument had an illegal value (e.g. typo in the method name).

int LSRKStepSetSSPMethodByName(void *arkode_mem, const char *emethod);

This function selects the LSRK SSP method by name. The list of allowable values for this input is above. LSRKStepCreateSSP() defaults to using ARKODE_LSRK_SSP_S_2.

Arguments:

arkode_mem – pointer to the LSRKStep memory block.
emethod – the method name.

Return value:

ARK_SUCCESS if successful
ARK_ILL_INPUT if an argument had an illegal value (e.g. typo in the method name).

int LSRKStepSetDomEigFn(void *arkode_mem, ARKDomEigFn dom_eig);

Specifies the dominant eigenvalue approximation routine to be used for determining the number of stages that will be used by either the RKC or RKL methods.

Arguments:

arkode_mem – pointer to the LSRKStep memory block.
dom_eig – name of user-supplied dominant eigenvalue approximation function (of type ARKDomEigFn()).

Return value:

ARK_SUCCESS if successful
ARKLS_MEM_NULL if arkode_mem was NULL.
ARK_ILL_INPUT dom_eig = NULL and LSRKStep does not currently estimate this internally.

Note

This function is currently required when either the RKC or RKL methods are used.

int LSRKStepSetDomEigFrequency(void *arkode_mem, long int nsteps);

Specifies the number of steps after which the dominant eigenvalue information is considered out-of-date, and should be recomputed. This only applies to RKL and RKC methods.

Arguments:

arkode_mem – pointer to the LSRKStep memory block.
nsteps – the dominant eigenvalue re-computation update frequency. A value nsteps = 0 indicates that the dominant eigenvalue will not change throughout the simulation.

Return value:

ARK_SUCCESS if successful
ARKLS_MEM_NULL if arkode_mem was NULL.

Note

If LSRKStepSetDomEigFrequency routine is not called, then the default nsteps is set to \(25\) as recommended in [153]. Calling this function with nsteps < 0 resets the default value while nsteps = 0 refers to constant dominant eigenvalue.

int LSRKStepSetMaxNumStages(void *arkode_mem, int stage_max_limit);

Specifies the maximum number of stages allowed within each time step. This bound only applies to RKL and RKC methods.

Arguments:

arkode_mem – pointer to the LSRKStep memory block.
stage_max_limit – maximum allowed number of stages \((>=2)\).

Return value:

ARK_SUCCESS if successful
ARKLS_MEM_NULL if arkode_mem was NULL.

Note

If LSRKStepSetMaxNumStages routine is not called, then the default stage_max_limit is set to \(200\). Calling this function with stage_max_limit < 2 resets the default value. This limit should be chosen with consideration of the following proportionality: \(s^2 \sim - h\lambda\), where \(s\) is the number of stages used, \(h\) is the current step size and \(\lambda\) is the dominant eigenvalue.

int LSRKStepSetDomEigSafetyFactor(void *arkode_mem, sunrealtype dom_eig_safety);

Specifies a safety factor to use for the result of the dominant eigenvalue estimation function. This value is used to scale the magnitude of the dominant eigenvalue, in the hope of ensuring a sufficient number of stages for the method to be stable. This input is only used for RKC and RKL methods.

Arguments:

arkode_mem – pointer to the LSRKStep memory block.
dom_eig_safety – safety factor \((\ge 1)\).

Return value:

ARK_SUCCESS if successful
ARKLS_MEM_NULL if arkode_mem was NULL.

Note

If LSRKStepSetDomEigSafetyFactor routine is not called, then the default dom_eig_safety is set to \(1.01\). Calling this function with dom_eig_safety < 1 resets the default value.

int LSRKStepSetNumSSPStages(void *arkode_mem, int num_of_stages);

Sets the number of stages, s in SSP(s, p) methods. This input is only utilized by SSPRK methods.

ARKODE_LSRK_SSP_S_2 – num_of_stages must be greater than or equal to 2
ARKODE_LSRK_SSP_S_3 – num_of_stages must be a perfect-square greater than or equal to 4
ARKODE_LSRK_SSP_10_4 – num_of_stages cannot be modified from 10, so this function should not be called.

Arguments:

arkode_mem – pointer to the LSRKStep memory block.
num_of_stages – number of stages \((>1)\) for SSP(s,2) and \((n^2 = s \geq 4)\) for SSP(s,3).

Return value:

ARK_SUCCESS if successful
ARKLS_MEM_NULL if arkode_mem was NULL.
ARK_ILL_INPUT if an argument had an illegal value (e.g. SSP method is not declared)

Note

If LSRKStepSetNumSSPStages routine is not called, then the default num_of_stages is set. Calling this function with num_of_stages <= 0 resets the default values:

num_of_stages = 10 for ARKODE_LSRK_SSP_S_2
num_of_stages = 9 for ARKODE_LSRK_SSP_S_3
num_of_stages = 10 for ARKODE_LSRK_SSP_10_4

2.4.10.1.3. Optional output functions

int LSRKStepGetNumDomEigUpdates(void *arkode_mem, long int *dom_eig_num_evals);

Returns the number of dominant eigenvalue evaluations (so far).

Arguments:

arkode_mem – pointer to the LSRKStep memory block.
dom_eig_num_evals – number of calls to the user’s dom_eig function.

Return value:

ARK_SUCCESS if successful
ARK_MEM_NULL if the LSRKStep memory was NULL

int LSRKStepGetMaxNumStages(void *arkode_mem, int *stage_max);

Returns the max number of stages used in any single step (so far).

Arguments:

arkode_mem – pointer to the LSRKStep memory block.
stage_max – max number of stages used.

Return value:

ARK_SUCCESS if successful
ARK_MEM_NULL if the LSRKStep memory was NULL

2.4.10.1.4. LSRKStep re-initialization function

To reinitialize the LSRKStep module for the solution of a new problem, where a prior call to LSRKStepCreateSTS() or LSRKStepCreateSSP() has been made, the user must call the function LSRKStepReInitSTS() or LSRKStepReInitSSP(), accordingly. The new problem must have the same size as the previous one. This routine retains the current settings for all LSRKstep module options and performs the same input checking and initializations that are done in LSRKStepCreateSTS() or LSRKStepCreateSSP(), but it performs no memory allocation as it assumes that the existing internal memory is sufficient for the new problem. A call to this re-initialization routine deletes the solution history that was stored internally during the previous integration, and deletes any previously-set tstop value specified via a call to ARKodeSetStopTime(). Following a successful call to LSRKStepReInitSTS() or LSRKStepReInitSSP(), call ARKodeEvolve() again for the solution of the new problem.

One important use of the LSRKStepReInitSTS() and LSRKStepReInitSSP() function is in the treating of jump discontinuities in the RHS function. Except in cases of fairly small jumps, it is usually more efficient to stop at each point of discontinuity and restart the integrator with a readjusted ODE model, using a call to this routine. To stop when the location of the discontinuity is known, simply make that location a value of tout. To stop when the location of the discontinuity is determined by the solution, use the rootfinding feature. In either case, it is critical that the RHS function not incorporate the discontinuity, but rather have a smooth extension over the discontinuity, so that the step across it (and subsequent rootfinding, if used) can be done efficiently. Then use a switch within the RHS function (communicated through user_data) that can be flipped between the stopping of the integration and the restart, so that the restarted problem uses the new values (which have jumped). Similar comments apply if there is to be a jump in the dependent variable vector.

int LSRKStepReInitSTS(void *arkode_mem, ARKRhsFn rhs, sunrealtype t0, N_Vector y0);

Provides required problem specifications and re-initializes the LSRKStep time-stepper module when using STS methods.

Arguments:

arkode_mem – pointer to the LSRKStep memory block.
rhs – the name of the C function (of type ARKRhsFn()) defining the right-hand side function.
t0 – the initial value of \(t\).
y0 – the initial condition vector \(y(t_0)\).

Return value:

ARK_SUCCESS if successful
ARK_MEM_NULL if the LSRKStep memory was NULL
ARK_MEM_FAIL if memory allocation failed
ARK_NO_MALLOC if memory allocation failed
ARK_CONTROLLER_ERR if unable to reset error controller object
ARK_ILL_INPUT if an argument had an illegal value.

Note

All previously set options are retained but may be updated by calling the appropriate “Set” functions.

If an error occurred, LSRKStepReInitSTS() also sends an error message to the error handler function.

int LSRKStepReInitSSP(void *arkode_mem, ARKRhsFn rhs, sunrealtype t0, N_Vector y0);

Provides required problem specifications and re-initializes the LSRKStep time-stepper module when using SSP methods.

Arguments:

arkode_mem – pointer to the LSRKStep memory block.
rhs – the name of the C function (of type ARKRhsFn()) defining the right-hand side function.
t0 – the initial value of \(t\).
y0 – the initial condition vector \(y(t_0)\).

Return value:

ARK_SUCCESS if successful
ARK_MEM_NULL if the LSRKStep memory was NULL
ARK_MEM_FAIL if memory allocation failed
ARK_NO_MALLOC if memory allocation failed
ARK_CONTROLLER_ERR if unable to reset error controller object
ARK_ILL_INPUT if an argument had an illegal value.

Note

All previously set options are retained but may be updated by calling the appropriate “Set” functions.

If an error occurred, LSRKStepReInitSSP() also sends an error message to the error handler function.
